Project Description

LT-WPCA-40W (HV)

LED Wall Pack Fixture 40 watt Full Cutoff

  • LED wall pack fixture is perfect for smaller spaces or areas. And the wall pack lights are additional lighting rather than the main illumination source.

outdoor-led-wall-pack lights-full-cutoff
  • Full Cut-off style
  • Commercial grade die-casting housing
  • Light transmission PC refractor
  • 120 lumen per watt
  • Universal voltage operation
  • Color uniformity and even light distribution
  • Occupancy sensor available
  • Wall Mounted led lights
  • IP65-rated waterproof led wall pack fixture
  • ETL/cETL listed, CE & RoHs
  • DLC QPL
  • 5 years warranty

In short, led wall pack light fixtures are typically used in commercial and industrial applications. For examples,

  • Offices building,
  • Schools,
  • Hospitals,
  • Warehouses,
  • Garage,
  • Parking lots.
Performance
Model# LT-WPCA-40W LT-WPCA-40W-HV
Input Voltage  100-277 VAC 200-480VAC
Input Power 42 watts 42 watts
Power Factor >0.9 >0.9
Delivered Lumens (lm) 5045 5045
Efficacy (lm/W) 120 120
Color Rendering Index (CRI) 80 80
Color Temperature (CCT) 3000K, 4000K, 5000K, 5700K 3000K, 4000K, 5000K, 5700K
Beam Angle 120O 120O
Equivalent Wattage  150 Watts MH 150 Watts MH
Dimming Control Available Available
Dimensions
Product Length (Inches) 12.6 12.6
Product Width (Inches) 6.8 6.8
Product Height (Inches) 5.1 5.1
Gross Weight (lbs.) 6.7 6.7
Material
Housing High-duty aluminum alloy High-duty aluminum alloy
Diffuser Shatter Polycarbonate  Shatter Polycarbonate
Finish Bronze Bronze
Waterproof IP65 IP65
Longevity
L70 Life (Hours)  50000  50000
Warranty (Years)  5~10 (*)  5~10(*)
Certificate
US Std. DLC, ETL/cETL DLC, ETL/cETL
EN Std. CE, RoHs CE, RoHs
Available Accessories
Emergency Backup Available Available
Motion Sensor Available Available
Daylight Sensor Available Available
