IP69K Washdown LED High Bay (NSF Certified for Food Processing)
Your Wash-Down Friendly Lighting Solution.
Engineered specifically for food and beverage processing plants, pharmaceutical manufacturing, and heavy-duty washdown environments, our IP69K NSF-Certified LED High Bay light delivers uncompromising safety and photometric performance.
Standard industrial high bays fail in sanitary environments due to high-pressure cleaning and bacteria buildup. This specialized fixture is hermetically sealed to withstand daily high-temperature, high-pressure chemical washdowns while meeting the strictest food-grade safety standards. Secure your facility’s regulatory compliance, eliminate shatter risks, and drastically reduce maintenance overhead with a fixture built for extreme sanitation.
Food Processors: Brighter Lights, Easier Cleaning
NSF Rated LED Lighting – Your Secret Weapon for a Clean & Efficient Kitchen
Stop stressing about dirty lights and high bills! IP69K Food Grade LED Lights are built for the food prep battlefield.
- Food Grade – NSF certified
- IP69K Rated & Easy-Washing
- High Performance – 160-200 lumens per watt.
- Wattage Selectable Range 100W- 120W- 150W
- CCT Selectable Range 30K-40K-50K
- Long Lifetime – L70>50,000 hrs.
- 5-10 years limited Warranty
- Anti-Corrosion available
- Cert: ETL/cETL, CE & RoHS
Family Information | IP69K LED High Bay Light-NSF Rated
Sample: LT-LBAH-150W-HV-50K-EM/PC-W
| LT- | LBA | -H | -150CP | -50K | -EM/PC | -BK |
| Finish: Blank=White, BK=Black | ||||||
| Accessory: MS=Motion Sensor, PS=PIR Sensor, EM=Emergency Kit | ||||||
| CCT: 30K=3000K, 40K=4000K, 50K=5000K, 57K=5700K, T =3000K-4000K-5000K Tunable | ||||||
| Power: 100W, 150W, 200W, 240W, 300W, 150CP=100W-120W-150W Tunable, 200CP=100W-150W-200W Tunable | ||||||
| Voltage: Blank=100-277vac, H=200-480vac | ||||||
| Desc: IP69K LED High Bay Lights | ||||||
Specification | IP69K LED High Bay Light-NSF Rated
| Model# | Rating | Lumen Output | Voltage Option | CCT Option |
|
LT-LBA100 |
100W |
16,000~21,000 lm |
100-277VAC 200-480VAC |
Single CCT: 2700K-6500K |
|
LT-LBA150CP |
Selectable 100W-120W-150W |
16,000~24,000 lm |
30K-40K-50K Selectable | |
|
LT-LBA150 |
150W |
24,000~31,250 lm |
Single CCT: 2700K-6500K | |
|
LT-LBA200 |
200W |
32,000~42,000 lm |
Single CCT: 2700K-6500K |
Meet standards | IP69K LED High Bay Light-NSF Rated
| Certificate | NSF, ETL/cETL , CE, RoHS, IP69K |
| EMC/FCC/IC Standard | EN55015, EN61547, EN61000-3-2/3, FCC part 15, ICES-005 |
| Safety Stanard | UL1598, CAN/CSA -C.22.2 NO. 250.0, EN61347-1, EN61347-2-13, EN60598-2-1, EN60598-1 |
| NO. | Document |
| 1 | |
| 2 |
|
Building the Future – Excellence in Every Project
Strict Sanitary & Safety Compliance
Strict Sanitary & Safety Compliance
NSF Certified
Meets National Sanitation Foundation standards for use in food processing Splash Zones and Non-Food Zones.
IP69K Rated
Highest possible certification for protection against high-pressure, high-temperature washdowns.
UL / ETL Listed
Certified for wet-location electrical safety and reliability.
RoHS Compliant
Free of hazardous materials, ensuring a clean and safe manufacturing environment.
IP69K Extreme Washdown Survivability
Fully sealed against dust and water ingress, this fixture is rated IP69K—the highest protection level available. It easily withstands daily high-pressure (up to 1450 PSI), high-temperature (up to 80°C/176°F) water jets and harsh chemical cleaning agents without fogging or electrical failure.
CCT & Wattage Selectable
There are allowed 3 different wattages and color temperature adjustments in fields, such as 100W-150W-2000W and 3000K-4000K-5000K.
This flexible choice capability allows for a cost-effective method to reduce stocking inventory by 88% (1 SKU instead of 9).
Smooth, Bacteria-Resistant Housing
Designed for zero-contamination environments, the ultra-smooth, die-cast aluminum housing features no exposed screws, deep crevices, or exposed heat-sink fins. This prevents the accumulation of water, dust, and foodborne bacteria, making sanitation fast and perfectly compliant.
High Efficacy 160-200 LPW of NSF Rated LED Lighting
Delivering exceptionally high lumen output (up to 200+ lm/W) with superior color rendering (CRI>80), it ensures pristine visibility for quality control inspectors and facility personnel across high-ceiling washdown zones.
Shatterproof, No-Glass Construction (Food Safe)
Glass is a critical contamination hazard in food processing. This high bay utilizes a heavy-duty, impact-resistant polycarbonate lens, entirely eliminating the risk of glass shattering over active food production lines.
