Project Description
NFS-IP69K LED High Bay Light Fixture |
LED Food Processing Light
- Food Grade – NSF certified
- High Performance – Full fixture outputs up to 140 lumens per watt.
- Energy Efficiency – Replacing up to 400W MH by 150W high bay led lights. In extreme contrast to conventional metal-halides, IP69K led high bay lights can bring in 88% of energy savings.
- Power Option – 100W, 120W, 150W
- Long Lifetime – L70>50,000 hrs. At 8 hours daily use, Lightide’ high bay led lights are rated to last 17 years.
- Multi-Installation – Chain Pendant
- 10-year limited Warranty – Contact us for more detail.
- Listings -NSF, ETL/cETL, CE/RoHs. IP69K Rated.
Features & Benefits
Premium Chip
High-performance Philips /CREE 3030 SMD to get full fixture outputs 140 lumens per watt.
Easy-Washing
Easy to clean with high pressure water gun and dust-proof
Optical Design
Unique distribution optical design for beam angles mid 45°, wide 90°, and flat 120 °
Dimmable Available
Compatible with Lutron 1-10vdc dimmer and other dimmers.
NSF certified
NSF certified products have therefore passed a stringent set of evaluations to ensure food safety requirements and standards are met.
IP69K Rating
Provide protection against ingress of dust and high temperature, high pressure water – making products with this certification ideal for use in conditions where equipment must be carefully sanitized.
Motion Sensor
With insufficient ambient light, the sensor switches on the lamp when motion is detected.
10-year Waranty
Coming with Meanwell driver, it offers a 10-year limited warranty. Contact us for more detail.
IP69K LED High Bay Light fixture delivers efficient, uniform, high lumen output for high bay and low bay applications in industrial, retail and commercial interiors. It is an easy solution to indoor and outdoor area lighting needs in industrial and commercial applications.
IP69K Rated & Easy-Washing
High-protection rating of luminaires allow to clean with high pressure up to 100 bar and 80 degrees C hot water, and a variety of cleaning agents, alongside good chemical resistance.
A highly efficient high bay with contemporary looks, designed for food handling applications. Without fins to facilitate easy cleaning, making it suitable for food process environments.
NSF certified
NSF certified high bay light fixture has therefore passed a stringent set of evaluations to ensure food safety requirements and standards are met.
Super Brightness & High Performance
LMC’ UFO profile LED High Bay Lights feature high-performance chip to get fixture 140 lm/w lumen output. It can be equivalent to up to 600-1000 watts MH high bay replacement. high-performance 45, 90 and 120-degree optical design delivers clear, brighter light while using significantly less energy when compared to traditional high bay lighting. High color rendering level 80 above perfect for food retail stores, wholesale warehouses, grocery chains, malls, showrooms, and plants.
Easy Installation
Hook or pendant mount is an easy and fast installation. Recommended mounting height 20 feet to 35 feet.
Products Family Information
Sample: LT-UBHP-150W-50K-EM-PC
| Model# | Rating | Lumen Output | Voltage Option | CCT Option |
|
LT-UBHP-100W |
100W |
14000 lm |
100-277VAC / 200-480VAC |
2700-6500K |
|
LT-UBHP-120W |
120W |
16800 lm |
100-277VAC / 200-480VAC |
2700-6500K |
|
LT-UBHP-150W |
150W |
21250 lm |
100-277VAC / 200-480VAC |
2700-6500K |
Meet standards
| Certificate | NSF, ETL/cETL , CE, RoHs, IP69K |
| EMC/FCC/IC Standard | EN55015, EN61547, EN61000-3-2/3, FCC part 15, ICES-005 |
| Safety Stanard | UL1598, CAN/CSA -C.22.2 NO. 250.0, EN61347-1, EN61347-2-13, EN60598-2-1, EN60598-1 |
| NO. | Description | Document | Version | Date |
| 1 | Lightide NFS-IP69K LED High Bay Lights sales sheet | A | 2019-08 |
