  • Lightide-DLC-Linear-led high-bay-lights

Linear High Bay LED Lights Fixture | Tri-Proof

(LT-TPHB series)

    • Excellent Performance – Outputs up to 160 lumens per watt.
    • Excellent Driver – Taiwan Meanwell HLG series
    • Energy Efficiency – In extreme contrast to conventional metal-halides, this high bay LED lights can bring in 80% of energy savings.
    • Power Option – 80W, 120W, 150W, 200W
    • Long Lifetime – At 8 hours daily use, Lightide’ high bay LED lights are rated to last 17 years.
    • 10-year Warranty
    • Listings: DLC, ETL/cETL Wet Location. IP65 rating.
Datasheet
Inquiry To Us

Features & Benefits

DLC vandal-proof-fixture

Vandal Proof

1060 pure aluminum housing and shatter-proof polycarbonate cover.

meanwell-driver-for-linear-led-high-bay-lighting_outdoor flood lights led

Meanwell Driver

Taiwan Meanwell driver can be used for Class I, Division 2 Hazardous and work at -40OC~+70 oC.

high-lumen-output-efficacy

High Efficacy 160 LPW

160 lumens per watt of 80-120W led high bay lighting 400w MH equivalent.

Dimmable-led-garage lights_wallpack_high-bay-light fixture

1-10VDC Dim

Compatible with Lutron 1-10vdc dimmer and other dimmers. Contact us for more.

heat-sink-design-system-of-led-post light_outdoor lights

Heat Dissipation Solution

Pure 1060 aluminum heat sink to accelerate heat dissipation from the classic housing.

DLC IP65_66-_high bayLight-fixture_outdoor lights

IP65-Rated

IP65 waterproof structure suitable for wet and damp location, for example warehouse, supermarket, plant and parking garage etc.

10-years-warranty-for-Lightide-LED-HIGH-BAY-SHOP-Lights

10-Year Warranty

The linear high bay lights offers 10-year warranty, including the case, led chip, driver and cable.

DLC-QPL-LED-Canopy-light_highbay_post-top

DLC QPL

 Many utilities offer lucrative rebates for Lightide’ DLC QPL Lights LED. It is able to accelerate the payback.

Linear LED High Bay Lights feature pure aluminum housing and Meanwell driver. DLC premium of linear high bay lights can be used in Class I, Division 2 hazardous (Classified) location luminaries.  Surface or pendant mount kits are available.

IP65 rated linear LED high bay lights offer 10 years limited warranty.  2′ ~ 5′ length is available power from 80W to 200W. Glare-free and No flick of high bay led fixture perfects for office,  metro lighting, retail stores, warehouses, grocery chains, malls, and parking garages, etc.

Order Information

 Sample:  LT-TPHB04150-HV-50K-EM-F

LT-TPHB-04-150-HV-50K-EM-C


Finish: C=clear cover, Blanket=Frosty

Accessory: MS=Motion Sensor, PC=Photocell, EM=Emergency Kit
CCT: 30K=3000K, 40K=4000K, 50K=5000K, 57K=5700K
Voltage: Std.=100-277vac, HV=200-480vac
Power: 80W, 120W, 150W,  200W
Size: 02=2′, 03=3′, 04=4′, 05=5′, 08=8′
Desc: LED Tri-proof High Bay Lights



Specification

Model#Rating Lumen OutputEqiv.LengthVoltage CCT Option

LT-TPHB0280

80W

11200 lm

250w MH

2′

100-277VAC2700-6500K

LT-TPHB03120

120W

16800 lm

 400W MH

3′

100-277VAC2700-6500K

LT-TPHB04150

150W

21991 lm

400-600W MH

4′

100-277VAC2700-6500K

LT-TPHB05200

200W

28649 lm

1000W MH

5′

100-277VAC2700-6500K



Compliant Standards

CertificateDLC Premium, ETL/cETL Wet Location
EMC/FCC/IC StandardEN55015, EN61547, EN61000-3-2/3, FCC part 15, ICES-005
Safety StanardUL1598, CAN/CSA -C.22.2 NO. 250.0, EN61347-1, EN61347-2-13, EN60598-2-1, EN60598-1, UL924
NO.DescriptionDocumentVersionDate

1

Lightide Linear High Bay LED Light Fixture datasheet

Download
B2018-02
2Lightide Linear High Bay LED Light Fixture brochure
Download
A2019-01
