LED Parking Garage Light Fixtures
150 LPW | Emergency | Power & CCT Selectable
LED Parking garage light fixtures are surface mount or suspended overhead ceiling lights ideal for task and general ambient lighting. These led light fixtures can be built with a battery for emergency lighting. Moreover, these fixtures also can be selected power and CCT with slide switches.
- High Performance – 150 lumens per watt.
- UL94-V0 Flame Rating
- Power & CCT Selectable available
- 5-year Warranty – No-compromise warranty covered.
- Listings: DLC Premium, ETL/cETL, CE/ROHS
- Emergency Battery Backup is available.
Features & Benefits
Conduit Fitting-Liquid Tight Connector
The UL-approved straight liquid tight connector is used to terminate and seal metallic, and non-metallic “Type B” liquid-tight conduit to a steel outlet box or any other metallic enclosure in either dry or wet locations. This connector is furnished with a sealing ring and zinc locknut and is suitable for use in Class 1 Division 2, Class II, Divisions 1 & 2, and Class III, Divisions 1 & 2 per NEC 501.30 (B).
Vapor Tight & IP65 Rated
Linear led high bay vapor-tight lighting fixture is widely used for interior and exterior wet locations, such as car wash operations, workshops, airports, tunnels, maintenance areas, parking garages, and stairwells. Surface or pendant mount kits are available for 2 ft. – 8 ft. from 20~ 100 watts.
Emergency Backup
- UL924 & CEC Title-20 battery backup.
- Intelligent emergency detection function- The emergency high bay light can switch to emergency mode automatically when power is off.
- Overcharge protection, over-discharge protection, short-circuit protection
Power & CCT Selectable
Linear LED Garage Lights 4ft feature power selectable ranges of 32-44-50 watts and CCT selectable ranges of 3000K-4000K-5000K.
Order Information | LED Parking Garage Light Fixtures
Sample: LT-TPA2-20W-50K-PC
| LT- | TP | -B | -2 | -15 | -50K | -PC | -C | |
| Accessory: MS=Motion Sensor, PC=Photocell, EM=Emergency Backup | Cover Option: Blank=Frost, C=Clear | |||||||
| CCT: 30K=3000K, 40K=4000K, 50K=5000K, 57K=5700K, T=Selecable 3000K-4000K-5000K | ||||||||
| Power code: 20=20W, 36=40W, 36CP= Selecable 32W-40W-50W, 100=100W | ||||||||
| Length Code: 2=2′, 4=4′, 8=8′ | ||||||||
| Code: A, B, C, D | ||||||||
| Desc: LED Parking Garage Lights | ||||||||
Specification | LED Parking Garage Light Fixtures
| Model# | Rating | Lumen Output | Equivalent | Cover | Length | Voltage | CCT Option |
| LT-TPA220 | 20W | 3000 lm (Clear) | 2x16w CFL | Frost/Clear | 2′ | 100-277VAC/200-480VAC | 2700K-6500K |
| LT-TPA436 | 40W | 6000 lm (clear) | 2X36W CFL | Frost/Clear | 4′ | 100-277VAC/200-480VAC | 2700K-6500K |
| LT-TPA436CP(T) | Selectable 32W-44W-50W | 6000 lm (clear) | 2X56W CFL | Frost/Clear | 4′ | 100-277VAC/200-480VAC | 3000K-4000K-5000K Selectable |
| LT-TPA810 | 100W | 15000 lm (frosted) | 4X56W CFL | Frost/Clear | 8′ | 100-277VAC/200-480VAC | 2700K-6500K |
Compliant Standards | LED Parking Garage Light Fixtures
| Certificate | DLC Premium, ETL/cETL Wet Location |
| EMC/FCC/IC Standard | EN55015, EN61547, EN61000-3-2/3, FCC part 15, ICES-005 |
| Safety Stanard | UL1598, CAN/CSA -C.22.2 NO. 250.0, EN61347-1, EN61347-2-13, EN60598-2-1, EN60598-1, UL924 |
| NO. | Description | Document | Version | Date |
| 1 | Datasheet | A1 | 2022-01 | |
| 2 | Sales sheet | A | 2018-08 | |
| 3 | Installation Manual | B | 202 |
