Project Description

  • Lightide-ETL-_CETL-Listed-1200w-1500W-Stadium-Light-led-flood-lights

High Mast LED Stadium Lights | DMX LED Flood Lights

  • Cold Precision Forging
  • High TLCI >80 – Meet high-quality HDTV transmission requirements.
  • Excellent Performance – 130~140 lumens per watt.
  • Premium Chip – CREE/Philips Chip
  • Power Option – 400-500-800-1000-1200-1500 watts
  • Surge Protection – Separate 10KV surge protection device to avoid early failure
  • 5~7 years Warranty
  • ListingsETL/cETL, CE & RoHs, TUV, CB,  FCC and SAA
Datasheet
Inquiry To Us

Features & Benefits

High mast LED stadium lights are an industry-leading, innovative, energy-saving luminaire. Led stadium floodlight is compatible with DMX protocol to replace traditional 1000-2000W MH or HPS light sources for the flood light.

LED stadium flood lighting fixtures also offer high CRI and TLCI  of CREE or Philips LEDs for floodlighting. The low-work temperature, rugged construction, free-hand installation features. The idea for the illuminating football stadium, sports, parking lot, square,  warehouse, plant, architectural lighting stairwells, and high-bay retail installations where high-security illumination and energy savings are needed.

Click HERE for round outdoor led stadium lights and sports flood lights

Order Information

 Sample:  LT-HPSF-500W-HV-50K-90D-W

LT-HPRF-500W-HV-50K-90D-MX
       Control Mode: DM=1-10VDC Dimming, MX=DM512 protocol

Beam Angle: 10D=10, 25D=25, 45D=45o     60D=60o    90D=90o

CCT: 30K=3000K, 40K=4000K, 50K=5000K, 57K=5700K
Voltage: Blanket.=100-277vac,  HV=200-480VAC
Power:   400W, 500W, 800W, 1000W, 1200W, 1500W
Shape: SF=Square, RF=Round
Desc:  High Mast LED Flood Lights



Specification

Model#

Rating

Lumen Efficacy

Module QTY

Voltage Option

CCT Option

Waterproof



LT-HPSF-400W

400W

130~140 LPW

2PCS

100-277VAC / 200-480VAC

2700K ~ 6500K

IP 66REVIEW

LT-HPSF-500W

500W

130~140 LPW

2PCS

100-277VAC / 200-480VAC

2700K ~ 6500K

IP 66REVIEW

LT-HPSF-800W

800W

130~140 LPW

4PCS

100-277VAC / 200-480VAC

2700K ~ 6500K

IP 66REVIEW

LT-HPSF-1000W

1000W

130~140 LPW

4PCS

100-277VAC / 200-480VAC

2700K ~ 6500K

IP 66REVIEW

LT-HPSF-1200W

1200W

130~140 LPW

6PCS

100-277VAC / 200-480VAC

2700K ~ 6500K

IP 66REVIEW

LT-HPSF-1500W

1500W

130~140 LPW

6PCS

100-277VAC / 200-480VAC

2700K ~ 6500K

IP 66REVIEW



High Mast LED Stadium Lights meet standards as below.

CertificateETL/cETL,  TUV/CB/CE/FCC/SAA/RoHS
EMC/FCC/IC StandardEN55015, EN61547, EN61000-3-2/3, FCC part 15, ICES-005
Safety StanardUL1598, CAN/CSA -C.22.2 NO. 250.0, EN61347-1, EN61347-2-13, EN60598-2-1, EN60598-1

NO.DescriptionDocumentVersionDate
1Lightide HPSF series High Mast LED Stadium Flood Lights datasheet
Download
A2020-01
2Lightide HPSF series High Mast LED Stadium Flood Lights sales sheetDownloadA2020-01
