Project Description
UL924 LED High Bay Emergency Light Fixtures (UBA-EM series)
High bay led emergency lights not only can provide excellent lighting efficacy for illumination, but also provide reliable battery backup lighting. That is to say, they can get people out of the building in time under power outages, blackouts, fires, and lightning strikes, etc.
- Intelligent Emergency Detection Function.
- UL924 listed – 90~180 minutes of Backup Lighting
- DoE High Efficiency & CEC Title 20 Compliance.
- Integrated J-Box – No need wire to install directly.
- Excellent Performance – 140~160 lumens per watt.
- 5-year Warranty
- Listings -ETL/cETL, CE & RoHS, IP 65 rated.
Features & Benefits
NFPA 101 Compliant
An average of 1 foot candle and a minimum of 0.1 foot candle when installed according to guidelines.
Intelligent Battery
UL924 Recognized Intelligent Emergency Detection Function
High Efficacy 140+ LPW
High-performance output with 140+ lumens per watt.
IP65 Rated
IP65 rated waterproof for the indoor and outdoor damp/wet location.
Optical Design
Unique lens distribution design to for 60o , 90o and 120o for option.
Motion Sensor Available
The sensor is available to switch on the high bay light when motion is detected.
ETL/cETL/CE
ETL/cETL listed with standard UL1598, CAN/CSA -C.22.2 NO. 250.0. CE certified.
Long Term Warranty
5-10 years warranty. Easy and fast replacement is offered if any quality issue.
High Bay Emergency Lights Battery
|
|
|||||||||||||||
NFPA 101 CompliantEach battery backup high bay light fixture provides at least 90 min. of illumination, with an average of 1-footcandle and a minimum of 0.1-footcandle when installed according to guidelines. |
|
|||||||||||||||
Test Push Button
|
|
|||||||||||||||
LED Vs Metal Halide Lamp
|
|
|||||||||||||||
High Bay Emergency Lights ApplicationIn short, powder-coated finish high bay led emergency lights for rust and corrosion-proof. Therefore, waterproof IP65 rated indoor led high bay light fixture perfects for
|
 |
|||||||||||||||
White finish emergency battery backupUFO led high bay lights |
 |
High Bay Emergency Lights Order Information
Sample: LT-UBA320-150W-HV-50K-EM/PC-2H
| LT- | UB | A | -320 | -150W | -HV | -50K | -MS/EM | -Std. | |
| Emergency time: Std.=90 minutes, 2H=120 minutes, 3H=180 minutes | |||||||||
| Accessory: MS=Motion Sensor, EM=Emergency, PC=Photocell, DM=1-10VDC | |||||||||
| CCT: 30K=3000K, 40K=4000K, 50K=5000K, 57K=5700K | |||||||||
| Voltage: Blanket=100-277vac, MV=347vac (*) HV=277-488VAC (*) | |||||||||
| Power: 100W, 150W, 200W, 240W | |||||||||
| Dimension Code: 280, 320, 400 | |||||||||
| Type: A, B, C, D | |||||||||
| Desc: UFO LED High Bay Light | |||||||||
* External Dimming emergency driver
High Bay Emergency Lights Specification
| Model# | Rating | Lumen Output | Equiv. | Emergency | Voltage Option | CCT Option | |
| LT-UBA280-100W-EM | 100W | 14094 lm | 400W Metal Halide | 20W @ 1.5 hrs
30W |
100-277vac/347vac
277-480VAC (*) |
2700-6500K |  |
| LT-UBA320-150W-EM | 150W | 20945 lm | 600W Metal Halide | 20W @ 1.5 hrs
30W |
100-277vac/347vac
277-480VAC (*) |
2700-6500K | |
| LT-UBA400-200W-EM | 200W | 28009 lm | 600W MH | 20W @ 1.5 hrs
30W |
100-277vac/347vac
277-480VAC (*) |
2700-6500K | |
| LT-UBA400-240W-EM | 240W | 33400 lm | 1000W MH | 30W @ 1.5 hrs
40W |
100-277vac/347vac
277-480VAC (*) |
2700-6500K | |
* External Dimming emergency driver
High Bay Emergency Lights Standards
| Description | Compliant Standard |
| Certificate | ETL/cETL, CE & RoHS, IP65 For Wet Location |
| EMC/FCC/IC Standard | EN55015, EN61547, EN61000-3-2/3, FCC part 15, ICES-005 |
| Safety Stanard | UL1598, CAN/CSA -C.22.2 NO. 250.0, EN61347-1, EN61347-2-13, EN60598-2-1, EN60598-1,
UL924, CSA C22.2 NO.141, NFPA 101 Compliant |
| NO. | Description | Document | Version | Date |
| 1 | Lightide UFO LED High Bay Emergency Lights Datasheet |
